MASTERING YOUR BERNINA

1/04/02

artista Embroidery/7

BERNINA

artisa Embroidery

MASTERING

YOUR

BERNINA

- grasping both inner hoop and fabric/stabilizer, insert into the outer hoop, aligning the arrows

at the edges of both the inner and outer hoops

- do not distort the fabric when tightening the screw on the hoop

- hooped fabric should be taut, but not stretched

- remove template before stitching

Attaching and Removing Hoop

Owner's manual pg.___

Adjusting Embroidery Hoop

Owner's manual pg.___

• Calibrate the needle so that it is in the exact center of the hoop

• This must be done with the large or medium hoop attached to the module

- attach module, making sure it is properly connected

- attach large or medium hoop with the template inserted

- turn artista on

- press the SetUp button on the artista

- select Service

- select Adjustment of Hoop

- touch Check

- artista follows the contours of the hoop, stopping with the needle in the center position

- if necessary, use the positioning arrows to correct the needle position

- touch OK

- the embroidery hoop is now adjusted and the screen closes

- touch ESC to close the SetUp screen

Hoop Coding

Owner's manual pg.___

• Attach the desired hoop to module

• Raise the presser foot to the highest position (if necessary)

• Select the desired motif

- the hoop moves to read the “coding” on the hoop

• Hoop “coding” is read:

- 3 notches = large hoop

- 2 notches = medium hoop

- 1 notch = small hoop

• If the hoop is larger than the motif size, the hoop moves to the start position

• If the motif is too large for the hoop, a message will appear confirming this

- change hoops -or-

- resize the motif in Layout, then touch Check to re-read the coding

• Icons at the left of the screen indicate the available hoops; the most suitable hoop is highlighted
