11Operating Instructions
Inserting the Bobbin
Clockwise Turning of the Bobbin
The bobbin must turn clockwise.
Inserting the Bobbin
Insert the bobbin so that the thread winds
clockwise.
Pulling the Thread Under the Spring
Pull the thread to the left under the spring
until it lies in the T-shaped slit at the end of
the spring.
Threading the Upper Thread
Attaching the Thread Spool
• raise the needle and presser foot
• turn the power switch to «0» (off)
• attach the foam pad
• place spool on pin (thread winds clockwise)
• attach the appropriate spool disc -
diameter of spool determines disc size.
There must be no clearance between the
disc and the spool
• take thread through rear guide A
• then into slit of upper thread tension
A
Down
• pull thread down to the right of the take-
up cover to B
Up
• take thread up to the left of the cover to C
in the direction of the arrow, placing it in
the take-up lever
Down
• take thread down and through guides D
and E
!
Refer to the
safety instructions!
C
B
D
E
031508.50.04_0601_a640_EN
